The
Christie L2K1500 digital projector offers native
2K (2048 x 1080) resolution making it an affordable choice for large sized displays in higher education, houses of worship and rental/staging applications, while providing extreme brightness at 15,000 ANSI lumens with high definition images.
| Technology |
3LCD |
| Resolution |
2048 x 1080 2K |
| Brightness |
15,000 ANSI Lumens |
| Contrast |
3000:1 |
| Illumination |
4 x 380W Ushio NSHA lamp |
| Lamp Life |
2,000 hours, up to 3,000 in eco mode |
| Height |
13.7 (349 mm) |
| Width |
25.6 (650 mm) |
| Length |
32.1 (815 mm) |
| Weight |
102.5 lbs (46.5 kg) (without lens) |
| Image |
- 15,000 ANSI lumens
- 3000:1 contrast ratio
- > 90% brightness uniformity
|
| Display |
- 3 x 1.64” Inorganic LCD panels
- Native 2K (2048 x 1080) resolution
|
| Lamp |
- 4 x 380W Ushio NSHA
- Normal mode 2000 hours, eco mode 3000 hours
|
| Signal Compatibility |
- VGA through 2K (2048 x 1080)
|
| Video Signal |
- Accepts current HDTV/DTV formats (480i, 480P, 720P, 1080i, 1080p, 1080psf)
|
| Pixel Clock |
|
| Inputs, Control and Networking |
- DVI-D x 1 (HDCP Compliant)
- DVI-D x 1 (HDCP Compliant)
- HDMI x 1
- D-Sub 15 x 1
- BNC x 5 (R,G,B,H,V & Y, Pb/Cb, Pr/Cr & Composite)
- Mini DIN 4-pin (S-video)
- RJ-45 LAN x 1
- Dsub-9 x 1
- 2 x option input card slots
- Control port Dsub-9 x 1
- R/C Jack – Mini jack x 1
|
| Optical System |
- Power adjustable zoom, focus and lens shift
- Motorized Light Shutter
|
| Standard Accessories |
- Quick setup manual
- Real Color Management software instruction
- Lens spacer for optional lenses
- Light-block sheet
- Mounting clamp
- Lens cover strap
- Power cord
- AC cord UL type (NEMA 6-20P plug type) 3 meters
- Computer cable (Dsub15-Dsub15)
- Remote control
|
| Standard Accessories |
- DVI/Dsub15 input card
- 5 BNC/S-video input card
- SDI-Dual input card (HD-SDI only)
- Dual Link input card*
- 380W Ushio NSHA lamps
- Smoke filter kit
- Disposable smoke filter
- Robotic AutoFilter cartridge
*Required for full 2048 x 1080 resolution |
| Enhanced feature sets |
- 4DColor™ technology
- *Stackable design for redundancy or added brightness up to 24,000 lumens
- Auto-switching lamp (single lamp mode)
- Digital keystone feature (Max: V±30°, H±30°)
- Robotic AutoFilter cartridge (up to 12,000 hours) maintenance free operation
- Built-in RS 232c port
- Customizable start-up logo
- Selectable aspect ratio 4:3,16:9, 17:9
- Top loading lamps
- Intuitive graphical user interface
- Built-in keypad (power on/standby, menu, up, down, left, right arrows)
- Front and rear infrared sensors for IR keypad
- Carrying handles
- Auto discoloration prevention with 3D-AUCC technology
- Top access to LCD panels – simplifies cleaning and maintenance
- Optional smoke filter kit
- Optional input slots for additional connectivity
*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application |
| Power requirements |
- Operating voltage: 200-240V ±10%
- Operating current: 11.0A max 200V
- Operating power: 1850W (200-240V)
- Dissipation: 7,100 BTU/hr
|
| Dimensions (LxWxH) |
- Body size (LxWxH): 32.1 x 25.6 x 13.7″ (815 x 650 x 349mm)
- Weight: 102.5lbs (46.5kg) without lens
- Shipping size (LxWxH): 39.7 x 34.1 x 22.0″ (1008 x 865 x 560mm)
- Shipping weight: 125.7lbs (57.0kg)
|
| Noise |
- 51dBA standard mode
- 48dBA eco mode
|
| Operating environment |
- Temperature: 41°F to 104°F (5°C to 40°C)
- Humidity (non-condensing): 20-80%
- Altitude: 0-8858ft (0-2700m)
|
| Regulatory Approvals |
This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC):
- FCC, Part 15, Subpart B, Class A
- EN55022/CISPR22: Class A
- EN55024/CISPR24
- IEC 60950-1
- UL 60950-1
- CAN/CSA C22.2 No. 60950-1
- Directive (EC) 2002/95/EC (RoHS)
- Directive 2002/96/EC (WEEE)
- Regulation (EC) No. 1907/2006 (REACH)
|
| Limited Warranty |
- Projector: three years parts and labor
- Lamp: 500 hours or one year (whichever comes first)
- Contact an authorized Christie representative for full details of our limited warranty
|
Features
- 15,000 ANSI lumens brightness suitable for large size applications
- Native 2K resolution (2048 x 1080)
- 3000:1 contrast ratio for exceptional image clarity
- Equipped with HDMI and DVI-D input slots
- Same optional lens suite as Christie L2K1000, Christie LX1000 and Christie LX1500
- *Stackable design to deliver up to 30,000 ANSI lumens
- Robust four lamp design with optional smoke filter kit for use in staging events (including events with smoke/pyrotechnic effects)
- Low maintenance features – robotic AutoFilter, long lamp life, hot swappable lamps and user replaceable lamps
- 4D Color™ technology
** In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application
Set up and image adjustment is a breeze, even in the most challenging room environments with built-in 3D Keystone™ technology which ensures quick and easy image alignment. The Christie L2K1500 is also equipped with power adjustable lens shift for zoom and focus, and a motorized lens shutter to completely block light when required. It also has a four-lamp system that provides redundancy ensuring there are no interruptions to your presentation – ideal for live events.
The Christie L2K1500 uses the same suite of optional lenses compatible with the Christie L2K1000, Christie LX1000 and the Christie LX1500 which enables easy integration with these projectors, and ensures a lower cost of ownership.
This large venue projector, offers extreme brightness, high definition image quality and is backed by Christie’s industry-leading warranties,
service and support.
