The
Christie L2K1000 digital projector offers native
2K resolution (2048 x 1080) making it the high resolution choice for auditoriums, broadcast sets, houses of worship, large conference rooms, training facilities and rental/staging applications.
| Technology |
3LCD |
| Resolution |
2048 x 1080 2K |
| Brightness |
10,000 ANSI Lumens |
| Contrast |
3000:1 |
| Illumination |
Dual 380W Ushio NSHA lamp |
| Lamp Life |
2,000 hours, up to 3,000 in eco mode |
| Height |
10.5 (267.5 mm) |
| Width |
20.9 (530.0 mm) |
| Length |
29.8 (757.0 mm) |
| Weight |
60.9 lbs (27.6 kg) (without lens) |
| Image |
- 10,000 ANSI lumens
- 3000:1 contrast ratio
- > 90% brightness uniformity
|
| Display |
- 3 x 1.64” Inorganic LCD panels
- Native 2K (2048 x 1080) resolution
|
| Lamp |
- Dual 380W Ushio NSHA
- Normal mode 2000 hours, eco mode 3000 hours
|
| Signal Compatibility |
- VGA through 2K (2048 x 1080)
|
| Video Signal |
- Accepts current HDTV/DTV formats (480i, 480P, 720P, 1080i, 1080p, 1080psf)
|
| Pixel Clock |
|
| Inputs, Control and Networking |
- DVI-D x 1 (HDCP Compliant)
- HDMI x 1
- D-Sub 15 x 1
- BNC x 5 (R,G,B,H,V & Y, Pb/Cb, Pr/Cr & Composite)
- Mini DIN 4-pin (S-video)
- RJ-45 LAN x 1
- Dsub-9 x 1
- 2 x option input card slots
- Control port Dsub-9 x 1
- R/C Jack – mini jack x 1
|
| Optical System |
- Motorized zoom, focus and lens shift
- Mechanical Light Shutter
|
| Lenses |
Ships without a lens. Choose the lens appropriate for your application
- Lens 0.5-0.6:1 Ultra Short*
- Lens 1.2-1.5:1 Short*
- Lens 1.5-2.2:1 Short*
- Lens 2.2-2.9:1 Standard*
- Lens 2.8-5.2:1 Long*
- Lens 5.0-9.2:1 Ultra Long*
*Lens Memory settings available |
| Standard Accessories |
- Quick set-up manual
- Real color management software instruction
- Lens spacer for optional lenses
- Light block sheet
- Mounting clamp
- Lens cover strap
- AC cord UL type (NEMA 6-20P plug type) 3 meters
- AC cord European 2P plug type 3 meters
- Computer cable (Dsub15-Dsub 15)
- Remote control
|
| Optional Accessories |
- DVI/Dsub15 input card
- 5 BNC/S-video input card
- SDI-Dual input card
- Dual Link input card*
- 380W Ushio NSHA lamps
- AutoFilter cartridge
*Required for full 2048 x 1080 resolution
|
| Enhanced feature sets |
- 4DColor™ technology
- Illuminated control panel
- *Stackable design for added brightness
- Auto-switching lamp feature (single lamp mode)
- AutoFilter cartridge (up to 11,000 hours) maintenance free operation
- Digital keystone feature (Max: V±30°, H±30°)
- Built-in RS 232c port
- Customizable start-up logo
- Selectable aspect ratio 4:3,16:9, 17:9
- Top loading lamps
- Intuitive graphical user interface
- Built-in keypad (power on/standby, menu, up, down, left, right arrows)
- Front and rear infrared sensors for IR keypad
- Carrying handles
- Auto discoloration prevention with 3D-AUCC technology
- Top access to LCD panels- simplifies cleaning and maintenance
*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application |
| Power requirements |
- Operating voltage: 100-120 V AC +/- 10%; 220-240 V AC +/- 10%
- Operating current: 4.6A max at 200V AC; 11.2A max at 100V AC
- Operating power: 1000W (100-120V), 955W (100-240V)
- Dissipation: 3,582 BTU/hr
|
| Dimensions (LxWxH) |
- Body size (LxWxH): 29.8 x 20.9 x10.5″ (757.0 x 530.0 x 267.5mm)
- Weight: 60.9lbs (27.6kg) without lens
- Shipping size (LxWxH): 37.4 x 33.3 x 21.3″ (951.0 x 846.0 x 542.0mm)
- Shipping weight: 83.8lbs (38.0kg)
|
| Noise |
- 43dBA standard mode
- 39dBA eco mode
|
| Operating environment |
- Operating temperature: 41-104˚F (5-40˚C)
- Humidity (non-condensing): 20-80%
- Altitude: 0-8858ft (0-2700m)
|
| Regulatory Approvals |
This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC):
- FCC Part 15, Subpart B Class A
- EN55022/CISPR22: Class A
- EN55024/CISPR24
- IEC 60950-1
- UL 60950-1
- CAN/CSA C22.2 No. 60950-1
- Directive (EC) 2002/95/EC (RoHS)
- Directive 2002/96/EC (WEEE)
- Regulation (EC) No. 1907/2006 (REACH)
|
| Limited Warranty |
- Projector: three years parts and labor
- Lamp: 500 hours or one year (whichever comes first)
- Contact an authorized Christie representative for full details of our limited warranty
|
The Christie L2K1000 takes 3LCD technology to the next level in resolution and cost effective performance.
Features
- 10,000 ANSI lumens brightness suitable for medium to large size applications
- Native 2K resolution (2048 x 1080)
- 3000:1 contrast ratio for exceptional image clarity
- Same optional lens suite as Christie L2K1500, Christie LX1000 and Christie LX1500
- Low maintenance features – filters, long lamp life, and user replaceable lamps
- Easy to setup and use
- 4D Color™ technology
Set up and image adjustment is a breeze, even in the most challenging room environments with built-in 3D Keystone™ technology which ensures quick and easy image alignment. Christie L2K1000 has a center mount lens design and is equipped with motorized lens shift for zoom and focus.
The Christie L2K1000 uses the same suite of optional lenses compatible with the Christie L2K1500, Christie LX1000 and the Christie LX1500 which enables easy integration with these projectors, and ensures a lower cost of ownership.
The Christie L2K1000 offers HD+ resolution for absolutely brilliant displays and is backed by Christie’s industry-leading warranties,
service and support.
