Christie® DHD775-E provides trusted performance, reliability and exceptional image quality. This projector is ideal for small auditoriums, boardrooms, classrooms and houses of worship.
The Christie DHD775-E offers unrivalled value. You get:
- DLP® technology
- color matching
- image blending and warping
- projector stacking capabilities
- energy-saving features
- low maintenance costs
- industry-leading warranties and support.
| Technology |
1-chip DLP |
| Resolution |
HD 1920 x 1080 |
| Brightness |
7,000 center lumens |
| Contrast |
Up to 5000:1 |
| Illumination |
Dual 350W P-VIP |
| Lamp life |
1500 hrs minimum @ 350W2000 hrs typical @ |
| Length |
20.9″ (532mm) |
| Width |
18.0″ (456mm) |
| Height |
8.5″ (215mm) |
| Weight |
43.0 lb (19.5 kg) |
| Brightness |
- 7,000 center (6,400 ANSI) lumens
|
| Contrast |
|
| Display technology and resolution |
- 1-chip 0.65″ DMD
- 1920 x 1080 HD
|
| Lamp |
|
| Lamp life |
- 1500 hrs minimum @ 350W
- 2000 hrs typical @ 280W
|
| Input signal compatibility |
- HDTV formats VGA through to WUXGA (1920 x 1200)
- Horizontal and vertical scaling while maintaining aspect ratio, all inputs
|
| Pixel clock |
|
| Scan rates |
- Horizontal: 15 kHz to 100 kHz
- Vertical: 24 kHz to 85 kHz
|
| Inputs, control and networking |
- HDMI x 2
- Display port x 1
- RGBHV (5 BNC)
- HD15 x 1
- Composite video x 1 (RCA)
- S-Video x 1 (mini DIN)
- Component video (RCA)
- USB x 1 (type B mini) – display over USB
- USB x 1 (type A) – image viewer or WiFi dongle (optional)
- RJ45 x 1
- RS232 in
- Ethernet (10/100) RJ45 with ChristieNET connectivity
- Build-in backlit keypad
- Wired remote control (3.5mm stereo) – wire not included
|
| Optical system |
- Motorized zoom, focus and lens shift and mechanical light shutter
|
| Fixed lens |
|
| Zoom lenses |
- 1.2-1.5:1 zoom lens
- 1.5-2.0:1 zoom lens
- 2.0-4.0:1 zoom lens
- 4.0-7.0:1 zoom lens
|
| Offsets |
- Vertical: +134% (+ 720 pixels)/ – 40% (- 216 pixels)
- Horizontal: +/-20% (+/-192pixels)
|
| Standard accessories |
- Brightness color wheel
- IR remote w/ wired remote jack (wire not included)
- AC line cord
- HDMI-DVI cable with locking HDMI connector
- User manual
|
| Optional accessories |
- Wireless dongle
- Warp module
- Rich color wheel (RGBCMY)
- Stacking frame (must be used with Stacker Adapter Plate)
- Stacker plate
- Ceiling mount
- Ceiling mount extension rod
|
| Power requirements |
- Operating voltage: 100 VAC to 240 VAC @ 50/60 Hz
- Operating current: 9.6A max at 100V
- Power consumption: 920W max (dual lamp 350W), 755W eco mode (dual lamp 280W)
- Dissipation: 3139 BTU/hr max, 2576 BTU/hr eco mode
|
| Dimensions and weight |
- Size: (L x W x H): 20.9 x 18.0 x 8.5” (532 x 456 x 215 mm) excluding feet
- Shipping size: 23.3 x 38.0 x 15.4″ (591 x 965 x 390mm)
- Weight: 43 lb (19.5 kg)
- Shipping Weight: 58 lb (26.3 kg)
|
| Operating environment |
- Temperature: 40 – 95°F (5 – 35°C)
- Humidity: 0 – 80% non-condensing
|
| Regulatory approvals |
- UL/CSA/IEC 60950-1
- FCC Class A, CE, CCC, KC, Gost-R, PSE, C-tick, and South Africa.
- This product conforms to all relevant European directives, standards, safety, health and environmental concerns
- RoHS, REACH, WEEE
|
| Limited warranty |
- 3 years parts and labor (including light engine)
- Contact an authorized Christie representative for full details of our limited warranty
|
The Christie DHD775-E gives you exceptional image quality, flexible installation, and ease of operation.
Features
- dual-lamp design offers the choice to use the projector in dual-lamp or single-lamp mode. Dual-lamp mode maximizes brightness and is great for redundancy. Single lamp mode increases the lamp life.
- 1-chip DLP technology provides excellent image quality and reliability
- 24/7 use capability
- Dynamic Contrast enhances images by increasing the contrast ratio to 5000:1
- an optional wireless module makes the projector more flexible to use and easy to set up.
A full suite of lenses, input options and 360 degree projection give you the flexibility to pick what works best for your presentation. The Christie DHD775-E is ideal for fixed install applications. The optional stacking, blending and warping capabilities also make it a great option for staging applications.
This projector comes with a number of eco-friendly features that lower the total cost of ownership.
The Christie DHD775-E is backed by Christie’s industry-leading warranties,
service and support.
